Place of Origin : Beijing, China
Brand Name : 797AUDIO
Model Number : Shock Mount
Frequency : 20-20000
Mounting Type : microphone capsule
Size / Dimension : 34mm
Description : microphone capsule holder
Type : adjustable shock mount for microphone capsule
Weight (g) : 35.0
Price : $10.00/pieces >=1 pieces

This mounting post with saddle will fit most 34mm dual-backplate capsules. It fits easily into most of microphones (made by the 797 Audio factory). It is easily retrofitted into other microphones that have a single central hole drilled in the top plate of the chassis to accommodate a mounting post.
The screw needed to attach this post to the mic chassis is included.
Two M1.6x5mm screws are included for mounting the capsule to the saddle. If they are too long for your capsule, cut off 1-2mm of the threads with a heavy-duty wire cutter or Dremel tool.
The mount stands 7/8 inch (22mm) tall.
This saddle works with all dual-backplate, K67 and CK12-style capsules that we've seen. It is not a great choice for K47 capsules, because the mounting holes are offset toward one side of the saddle. They would force the capsule to sit forward relative to the center of the mount.
This mount is known to work well with the following capsules:



Interview, Live Chat, Recording, Broadcasting, Conference, Speech, Gaming,Singing, Entertainment,Etc.





Beijing 797 Audio Co.,Ltd. was founded in 1953 as an electric-acoustic manufacturer with long history in the field of microphone,speaker system,audio,etc.




Beijing 797 Audio Co., Ltd. has set microphone, speaker national standard, industry standard for audio, It covers audio products, public broadcasting and other fields. We already get over 70 patents on microphones and loudspeakers. We get ISO9001,ISO14001,ISO45001,and CE certificates, And our products have also been winning awards continuously.





|
|
34mm Shock Mount for Microphone Capsule 797AUDIO Large Diaphragm Condenser Capsules Holder Images |
